dji Inspire 2 Series User Manual

60
©
2018 DJI All Rights Reserved.
INSPIRE 2 SERIES User Manual
When an aircraft exceeds a specied limit, the pilot can still control the aircraft but it will
be unable to y any farther.
When an aircraft exceeds the max radius it automatically ies back within range when
GPS signal is strong.
For safety reasons, do not y near airports, highways, railway stations, railway lines, city
centers, or other sensitive areas. Only y aircraft in areas that are within your direct line of
sight.
Strong GPS Signal
Restriction Description DJI GO 4 App Message
Max Altitude
Aircraft's altitude cannot exceed
the specied value.
Maximum Flight Altitude reached. Adjust
your altitude using FC Settings if required.
Max Radius
Flight distance cannot exceed
the specied value.
Maximum Flight Distance reached.
Adjust your distance using FC Settings if
required.
Weak GPS Signal
Restriction Description DJI GO 4 App Message
Max Altitude
Altitude is restricted to 26 ft (8 m) when
GPS signal is weak and the Vision System
is activated. Altitude is restricted to 98 ft
(30 m) when GPS signal is weak and the
Vision System is deactivated.
Maximum Flight Altitude
reached. Adjust your altitude
using MC Settings if required.
Max Radius No limit. N/A
Maximum Flight Altitude
Max Radius
Home Point
Height of aircraft when turned on

dji Inspire 2 Series Specifications

General

Battery Capacity	4280 mAh
Battery Voltage	22.8 V
Operating Temperature	-20°C to 40°C
Camera Compatibility	Zenmuse X7, Zenmuse X5S, Zenmuse X4S
Transmission Distance	7 km (FCC), 4 km (CE)
Max Ascent Speed	5 m/s
Max Descent Speed	4 m/s
Operating Frequency	2.4 GHz and 5.8 GHz
Gimbal	3-axis
Satellite Systems	GPS/GLONASS
Charging Temperature Range	5°C to 40°C
Live View Quality	1080p
Max Tilt Angle	35°
Transmitter Power (EIRP)	26 dBm (FCC), 20 dBm (CE)
Video Transmission System	DJI Lightbridge
