MATRICE 200 Series User Manual
4. Connect the Datalink Pro Ground System to the computer and toggle the 4-position Switch to the
COMBO position to activate the Datalink Pro Ground System.
5. Connect the Datalink Pro Air System to the computer and toggle the 4-position Switch to the
COMBO position to activate the Datalink Pro Air System.
Using the D-RTK
Use the D-RTK in an open environment free from radio interference and follow the procedures
below:
1. Power on the Ground System, and wait for the Working Status LED to turn solid green.
2. Power on the Air System, and wait for the aircraft Flight Status LED blinks green and blue
alternately.
 &OTVSFUIBUUIF%35,(SPVOE4ZTUFNJTQPXFSFEPOmSTU%0/05QPXFSPOUIFBJSDSBGU
before the D-RTK Ground System’s Working Status LED is solid green.
Set the Flight Mode Switch to P mode or S mode.
The Datalink Pro Ground System’s 4-position Switch should be toggled to the UART
position and the Air System should be toggled to the CAN position when used.
8SGDWLQJWKH*URXQG6\VWHP·V3RVLWLRQ
Each time it is used, the Ground System automatically detects the offset distance from its previous
QPTJUJPO*GUIFPGGTFUEJTUBODFJTNFUFSTUIF(SPVOE4ZTUFNXJMMVQEBUFUIFOFXQPTJUJPO
coordinates automatically. If the position has changed but the Ground System does not update
BVUPNBUJDBMMZZPVXJMMOFFEUPVQEBUFNBOVBMMZ1SFTTUIF6QEBUFCVUUPOBOEIPMEGPSmWFTFDPOET
until the Ground System recalculates the position coordinates. The DJI GO 4 app will prompt you
once the Ground System’s position has been updated successfully.
Micro USB
