MATRICE 200 Series User Manual
 .PVOUUIF;FONVTF95POUPUIFBJSDSBGUCZTFDVSJOHUIFHJNCBMBEBQUFS
Single Downward Gimbals
The dual downward gimbal connector is mounted onto the aircraft at the factory. To use the M210
PS.35,TTJOHMFEPXOXBSEHJNCBMTJUJTOFDFTTBSZUPmSTUSFNPWFUIFEVBMEPXOXBSEHJNCBM
connector and mount the single downward gimbal connector.
1. Detach the dual downward gimbal connector from the aircraft by gently removing the three
2. Remove the four screws on the top of the dual downward gimbal connector.
