3. Disconnect the gimbal signal control cable and gimbal video cable from the dual downward
gimbal connector.
4. Remove the three screws on the top of the single downward gimbal connector.
5. Connect the gimbal signal control cable and gimbal video cable to the single downward gimbal
connector.
6. Tighten the cover onto the single downward gimbal connector with screws.
