dji MATRICE 200 series User Manual

©
2018 DJI All Rights Reserved.
7
MATRICE 200 Series User Manual
Installing the Landing Gears Unfolding the Aircraft
1
2
3
Unfold the frame arm, slide the arm lock to the end of the frame
arm, then rotate it about 90° until the silver line lies within the
range of the
icon.
For the M200 series, only mount the D-RTK antennas to the M210 RTK.
Unfold the D-RTK antennas and tighten the screws.
Assemble the Aircraft
5IJTNBOVBMVTFTUIF.35,BOE;FONVTF;BTBOFYBNQMFUPEFNPOTUSBUFTFUVQBOEVTBHF
2
1
Unfolding the D-RTK Antennas
Mounting the Propellers
Propellers
without silver
rings go on
motors without
any marks.
Press the propeller down
onto the mounting plate
and rotate in the lock
direction
until secure.
Propellers
with silver
rings go on
motors with
the same
color marks.
Check that the propellers are secure
CFGPSFFBDInJHIU

dji MATRICE 200 series Specifications

General

Max Takeoff Weight	6.14 kg
Ingress Protection Rating	IP43
Satellite Systems	GPS/GLONASS
Max Flight Time	38 minutes
Hovering Accuracy	Vertical: ±0.5 m, Horizontal: ±1.5 m
Diagonal Size	650 mm
Charging Temperature Range	5°C to 40°C
Operating Temperature Range	-4°F to 113°F (-20°C to 45°C)
