MATRICE 200 Series User Manual
Power on the Intelligent Flight Battery and toggle the USB Mode Switch left, and connect the aircraft
and the PC via a double A port USB cable for aircraft parameters configuration and firmware
update.
Toggle the USB Mode Switch to the middle RTK position, and connect the aircraft and the PC via a
EPVCMF"QPSU64#DBCMFGPSUIFCVJMUJO%35,"JSTZTUFNBDUJWBUJPOBOEmSNXBSFVQEBUF
Toggle the USB Mode Switch right and connect the aircraft and mobile device via a Micro USB cable.
Extended Power Port (XT30)
Used to supply power for other device, whose voltage range is from 18 V to 26 V with a current of 2 A.
.BLFTVSFZPVSEFWJDFJTTBUJTmFEXJUIUIFWPMUBHFBOEDVSSFOUSFRVJSFNFOU
USB Mode Switch
