MATRICE 200 Series User Manual
Using the Charging Port
Place the battery into the remote controller, and connect connector B of the battery power port, then
connect the battery charger to a power outlet (100-240V, 50/60Hz). When charging is complete, the
#
#
"
Power Qutlet
_7
Charging Time: 2 hours and 24 minutes
Using the Charging Hub
Place the battery into the Charging Hub, and connect connector B of the battery charger to the
charging hub, then connect the battery charger to a power outlet (100-240V, 50/60Hz). The
Charging Hub will intelligently charge batteries in sequence according to battery power levels from
high to low. The buzzer will begin beeping when charging is complete. Remove the battery or turn
off the Buzzer Switch to stop it.
5IFDIBSHJOHIVCCMJOLTHSFFOXIJMFDIBSHJOHBOEUVSOTTPMJEHSFFOXIFODIBSHJOHJTmOJTIFE
#
"
#
Power Qutlet
_7
Using the WCH2 Charging Hub, charging time is approximately 1 hour and 11 minutes (for one battery).
Place the battery into the Charging Hub, and connect connector B of the battery charger to
the charging hub, then connect the battery charger to a power outlet (100-240V, 50/60Hz).
USB power supply port can be used to charge the mobile device of 5V/2A.
Refer to the WCH2 Charging Hub User Guide for more details.
