MATRICE 200 Series User Manual
Pitch Pan
Gimbal Operation Modes
Three gimbal operation modes are available. Switch between the different operation modes in DJI
GO 4's Camera View. Note that your mobile device must be connected to the remote controller for
changes to take effect. Refer to the table below for details:
Roll
Follow Mode Gimbal pan cannot be controlled in this mode.
Free Mode The Gimbal’s motion is independent of the aircraft’s orientation.
Reset
Tap and the gimbal will pan to realign with the aircraft's nose. The tilt
angle will remain unchanged during re-alignment.
Gimbal pan cannot be controlled in Follow Mode. In Free Mode, press and hold the C1
Button while rotating the control dial to adjust gimbal yaw.
The gimbal will be in free mode when the Slave remote controller controls the gimbal in
Dual Remote Controller Mode.
