DJI Mavic 3 Classic User Manual
18
©
2022 DJI All Rights Reserved.
When the aircraft is powered on but the motors are not running, the front LEDs glow solid red
to display the orientation of the aircraft.
When the aircraft is powered on but the motors are not running, the aircraft status indicators
display the status of the flight control system. Refer to the table below for more information
about the aircraft status indicators.
Aircraft Status Indicator States
Normal States
Alternating red, green,
and yellow
Blinks
Turning on and performing
self-diagnostic tests
×4
Yellow Blinks four times Warming up
Green Blinks slowly GNSS enabled
×2
Green Periodically blinks twice Vision Systems enabled
Yellow Blinks slowly NO GNSS or Vision Systems
Warning States
Yellow Blinks quickly Remote controller signal lost
Red Blinks slowly Low battery
Red Blinks quickly Critically low battery
——
Red Solid Critical error
Alternating red and yellow Blinks quickly Compass calibration required
After the motor starts, the front LEDs blink red and green alternately and the aircraft status
indicators blink green. The green lights indicate the aircraft is a UAV and the red lights indicate
the heading and position of the aircraft.
• If the front LEDs are set to auto in DJI Fly, the front LEDs turn off automatically when
shooting to obtain better footage. Lighting requirements vary depending on the
region. Observe local laws and regulations.
Aircraft Status Indicators
DJI Mavic 3 Classic has front LEDs and aircraft status indicators.
Front LED
Aircraft Status Indicator
Front LED
Aircraft Status Indicator
