DJI Mavic 3 Classic User Manual
63
©
2022 DJI All Rights Reserved.
Camera View
1. Flight Mode
N: Displays the current flight mode.
2. System Status Bar
In-Flight : Indicates aircraft flight status and displays various warning messages.
3. Battery Information
80
24'17"
: Displays the current battery level and remaining flight time. Tap to view more
information about the battery.
4. Video Downlink Signal Strength
: Displays the video downlink strength between the aircraft and remote controller.
5. Vision Systems Status
: The left side of the icon indicates the status of the Forward, Backward, and Lateral
Vision Systems and the right side of the icon indicates the status of the Upward and
Downward Vision Systems. The icon is white when the Vision System is working normally
and red when the Vision System is unavailable.
6. GNSS Status
20
: Displays the current GNSS signal strength. Tap to check the GNSS signal status. The
Home Point can be updated when the icon is white, which indicates the GNSS signal is
strong.
7. System Settings
: Tap to view information about safety, control, and transmission.
N ModeN Mode
80
20
20
80 m
80 m
4.6m/s4.6m/s
DD
3m/s
3m/s
HH
150 m
In-Flight
AF
1.0x
12 26
80
12
26
06:21
Storage
EV
RES&FPS
4K 60
+0.7
1 2
3 4 5 6 7
8
9
10
11
1213141516
17
18
