47
©
2022 DJI All Rights Reserved.
Remote Controller
DJI RC
When used with DJI Mavic 3 Classic, DJI RC remote controller features O3+ video transmission,
works at both 2.4 GHz and 5.8 GHz frequency bands. It is capable of selecting the best
transmission channel automatically and can transmit up to 1080p 60fps HD live view from the
aircraft to the remote controller at a distance of up to 15 km (compliant with FCC standards,
and measured in a wide open area without interference). The DJI RC is also equipped with a
5.5-in touchscreen (1920×1080 pixel resolution) and a wide range of controls and customizable
buttons, enabling users to easily control the aircraft and remotely change the aircraft settings.
The built-in 5200 mAh battery with a power of 18.72 Wh provides the remote controller with a
maximum operating time of four hours. The DJI RC comes with many other functions such as
Wi-Fi connection, built-in GNSS (GPS+BeiDou+Galileo), Bluetooth, built-in speakers, detachable
control sticks, and microSD storage.
Charging the Battery
Use a USB-C cable to connect a USB
charger to the USB-C port of the remote
controller. The battery can be fully charged
in about 1 hour and 30 minutes with a
maximum charging power of 15 W (5V/3A).
Using the Remote Controller
Powering On/Off
Press the power button once to check the
current battery level.
Press and then press again and hold to power
the remote controller on or off.
Controlling the Gimbal and Camera
Focus/Shutter Button: Press halfway down to
auto focus and press all the way down to take
a photo.
Record Button: Press once to start or stop
recording.
Camera Control Dial: Use to adjust the zoom
by default. The dial function can be set to
adjust the focal length, EV, aperture, shutter
speed, and ISO.
Gimbal Dial: Use to adjust the tilt of the gimbal.
Gimbal Dial
Record Button
Camera
Control
Dial
Focus/Shutter Button
