DJI Mavic 3 Classic User Manual
43
©
2022 DJI All Rights Reserved.
Battery Protection Mechanisms
LED1 LED2 LED3 LED4 Blinking Pattern Status
LED2 blinks twice per second Overcurrent detected
LED2 blinks three times per second Short circuit detected
LED3 blinks twice per second Overcharge detected
LED3 blinks three times per second Over-voltage charger detected
LED4 blinks twice per second Charging temperature is too low
LED4 blinks three times per second Charging temperature is too high
If the battery protection mechanisms activate, in order to resume charging it is necessary
to unplug the battery from the charger and plug it in again. If the charging temperature
is abnormal, wait for the charging temperature to return to normal, and the battery will
automatically resume charging without requiring to unplug and plug in the charger again.
Inserting the Intelligent Flight Battery
Insert the Intelligent Flight Battery into the battery compartment of the aircraft. Make sure it is
mounted securely and that the battery buckles click into place.
Removing the Intelligent Flight Battery
Press the textured part of the battery buckles on the sides of the Intelligent Flight Battery to
remove it from the compartment.
2
1
• DO NOT detach the battery when the aircraft is powering on.
• Make sure that the battery is mounted firmly.
Click
