dji MAVIC 2 ENTERPRISE Advanced User Manual

MAVIC 2 ENTERPRISE Advanced
User Manual
12
©
2021 DJI All Rights Reserved.
17. Record Button
Press to start recording video. Press again
to stop recording.
18. HDMI Port
For video output.
19. microSD Card Slot
Use to insert a microSD card.
20. USB-A Port
Use to connect external devices.
21. Focus/Shutter Button
Press once to take photos according to the
mode selected in DJI Pilot.
22. Camera Settings Dial/Gimbal Dial
Turn to adjust the zoom of the camera.
23. Air Vent
Used for heat dissipation. DO NOT cover
the air vent during use.
24. Sticks Storage Slot
Use to store a pair of control sticks.
25. Customizable Button C2
The default configuration is playback. The
conguration can be set in DJI Pilot.
1
6
9999
1010101010101010101010101010
10
12
10
13
77
8
11
3
2
4
14
15
23
27
28
26
16
17
18 19
20
21
22
24
25
5
26. Speaker
Outputs sound.
27. Customizable Button C1
The default configuration is center focus.
The conguration can be set in DJI Pilot.
28. Air Intake
Used for heat dissipation. DO NOT cover
the air intake during use.

dji MAVIC 2 ENTERPRISE Advanced Specifications

General

Type	Quadcopter
Foldable	Yes
Product color	Gray
Construction type	Ready-to-fly (RTF)
Charging time	90 min
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	5000 mAh
Cables included	AC, USB Type-C
Maximum speed	20 m/s
Frequency band	2.4 - 5.85 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum flight time	31 min
Maximum ascent speed	6 m/s
Maximum descent speed	7 m/s
Maximum flight altitude	6000 m
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Horizontal hover accuracy	0.1 m
Maximum operating distance	10000 m
Number of propeller blades	2
Maximum yaw angular velocity	200 °/sec
Megapixel	48 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	2/3/5/7/10/15/20/30/60 s
Image formats supported	JPEG
Video formats supported	MP4
Maximum image resolution	8000 x 6000 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	87 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	24 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Built-in processor	-

Weight and Dimensions

Depth	455 mm
Width	290 mm
Height	225 mm
Weight	1710 g
Battery weight	297 g
Transmitter weight	630 g
Takeoff weight (max)	1100 g
