MAVIC 2 ENTERPRISE Advanced
User Manual
©
2021 DJI All Rights Reserved.
27
Charging the Battery
Fully charge the Intelligent Flight Battery before using for the rst time:
1. Connect the AC power adapter to a power source (100-240 V, 50/60 Hz).
2. Attach the Intelligent Flight Battery to the AC power adapter using the battery charging cable with
the battery powered o.
3. The battery level LEDs display the current battery level during charging.
4. The Intelligent Flight Battery is fully charged when the battery level LEDs are all powered off.
Detach the AC power adapter when the battery is fully charged. It takes 1 hour and 30 minutes to
fully charge.
DO NOT charge an Intelligent Flight Battery immediately after ight as the temperature may be too high.
Wait until it cools down to room temperature before charging again.
The AC power adapter stops charging the battery if the battery cell temperature is not within the
operating range of 41° to 104° F (5° to 40° C). The ideal charging temperature is 71.6° to 82.4° F (22°
to 28° C).
The Battery Charging Hub (not included) can charge up to four batteries. Visit the ocial DJI online store
for more information.
AC Power Adapter
Intelligent Flight Battery
Power Outlet
Battery Level LEDs During Charging
LED1 LED2 LED3 LED4
Battery Level LEDs
During Charging
Battery Level 0%~25% 25%~50% 50%~75% 75%~100%
Battery Protection
Battery Protection Mechanisms
LED1 LED2 LED3 LED4 Blinking Pattern Battery Protection Description
LED 2 blinks twice per second Overcurrent detected
LED 2 blinks three times per
second
Short circuit detected
LED 3 blinks twice per second Overcharge detected
LED 3 blinks three times per
second
Charger overvoltage detected
LED 4 blinks twice per second Charging temperature is too low
LED 4 blinks three times per
second
Charging temperature is too high
