DJI Mavic 3 User Manual
47
©
2021 DJI All Rights Reserved.
Camera View
1. Flight Mode
N : Displays the current ight mode.
2. System Status Bar
In-Flight : Indicates aircraft ight status and displays various warning messages.
3. Battery Information
80
24'17"
: Displays the current battery level and remaining ight time. Tap to view more information about
the battery.
4. Video Downlink Signal Strength
RC
: Displays the video downlink strength between the aircraft and remote controller.
5. Vision Systems Status
: The left side of the icon indicates the status of the Forward, Backward, and Lateral Vision Systems
and the right side of the icon indicates the status of the Upward and Downward Vision Systems. The icon is
white when the vision system is working normally and red when the vision system is unavailable.
6. GNSS Status
20
: Displays the current GNSS signal strength. Tap to check the GNSS signal status. The Home Point
can be updated when the icon is white, which indicates the GNSS signal is strong.
7. System Settings
: Tap to view information about safety, control, and transmission.
Safety
Flight Assistance: Upward, Forward, Backward, and the Lateral vision systems are enabled after setting
Obstacle Avoidance to Bypass or Brake. The aircraft cannot sense obstacles if Obstacle Avoidance is
disabled.
Radar Map Display: When enabled, the real-time obstacle detection radar map will be displayed.
Flight Protection: Tap to set the max altitude, max distance, Auto RTH altitude (default altitude is 100 m), and
to update the Home Point.
Sensors: Tap to view the IMU and compass status and start to calibrate if necessary.
N ModeN Mode
80
17
20
1x
AF
In-Flight
1 2 3 4 5 6 7
8
9
10
11
12 13 14 15 16
17
18
