dji Mavic 3 User Manual

DJI Mavic 3 User Manual
62
©
2021 DJI All Rights Reserved.
Firmware Update
Use DJI Fly or DJI Assistant 2 (Consumer Drones Series) to update the aircraft rmware.
Using DJI Fly
When you connect the aircraft or remote controller to DJI Fly, you will be notified if a new firmware
update is available. To start updating, connect your remote controller or mobile device to the internet
and follow the onscreen instructions. Note that you cannot update the rmware if the remote controller
is not linked to the aircraft. Internet is required.
Using DJI Assistant 2 (Consumer Drones Series)
Update the aircraft and remote controller rmware separately using DJI Assistant 2 (Consumer Drones
Series).
Follow the instructions below to update the aircraft rmware through DJI Assistant 2 (Consumer Drones
Serie
1. Launch DJI Assistant 2 (Consumer Drones Series) and log in with your DJI account.
2. Power on the aircraft and connect the aircraft to a computer via the USB-C port.
3. Select DJI Mavic 3 and click on Firmware Updates on the left panel.
4. Select the rmware version that you wish to update to.
5. Wait for the rmware to download. The rmware update will start automatically.
6. The aircraft will reboot automatically after the rmware update is complete.
Follow the instructions below to update the remote controller rmware through DJI Assistant 2 (Consumer
Drones Series):
1. Launch DJI Assistant 2 (Consumer Drones Series) and log in with your DJI account.
2. Power on the remote controller and connect to a computer via the USB-C port using a Micro USB
cable.
3. Select DJI Mavic 3 Remote Controller and click on Firmware Updates on the left panel.
4. Select the rmware version that you wish to update to.
5. Wait for the rmware to download. The rmware update will start automatically.
6. Wait for the rmware update to be completed.
Make sure follow all the steps to update rmware. Otherwise, the update may fail.
The firmware update will take approximately 10 minutes. It is normal that the gimbal goes limp,
aircraft status indicators blink, and the aircraft reboots. Wait patiently until the update is complete.
Make sure the computer has access to the internet.
Before performing an update, make sure the Intelligent Flight Battery is at least 40% charged and the
remote controller is at least 30% charged.
Do not disconnect the aircraft from the computer during an update.
After-Sales Information
Visit https://www.dji.com/support to learn more about after-sales service policies, repair services, and
support.

dji Mavic 3 Specifications

General

Type	Quadcopter
Product color	Black
Maximum speed	19 m/s
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	40 min
Maximum flight time	46 min
Maximum ascent speed	8 m/s
Maximum descent speed	6 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	30000 m
Maximum pitch angular velocity	200 °/sec
USB ports quantity	2
Operating frequency	2400000 MHz
Battery voltage	15.4 V
Battery capacity	5000 mAh
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Camera shutter speed	8 - 1/8000 s
Image formats supported	DNG, JPEG
Video formats supported	H.264, H.265
Maximum image resolution	5280 x 3956 pixels
Maximum video resolution	5120 x 2700 pixels
Field of view (FOV) angle	84 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	-
Moving control functions	Backward, Downward, Forward, Upward

Weight and Dimensions

Depth	221 mm
Width	96.3 mm
Height	90.3 mm
Weight	895 g
Battery weight	335.5 g
