DJI Mavic 3 User Manual

Intelligent Flight Battery

The DJI Mavic 3 Intelligent Flight Battery is a 15.4 V, 5000 mAh battery with smart charging and

discharging functionality.

Battery Features

1. Battery Level Display: The LED indicators display the current battery level.

2. Auto-Discharging Function: To prevent swelling, the battery automatically discharges to 96% of the

battery level when it is idle for three days, and automatically discharges to 60% of the battery level

when it is idle for nine days. It is normal to feel moderate heat being emitted from the battery during

the discharging process.

3. Balanced Charging: During charging, the voltages of the battery cells are automatically balanced.

4. Overcharge Protection: The battery stops charging automatically once fully charged.

5. Temperature Detection: In order to protect itself, the battery only charges when the temperature is

between 5° and 40° C (41° and 104° F).

6. Overcurrent Protection: The battery stops charging if an excess current is detected.

7. Over-Discharge Protection: Discharging stops automatically to prevent excess discharge when the

battery is not in use. Over-discharge protection is not enabled when the battery is in use.

8. Short Circuit Protection: The power supply is automatically cut if a short circuit is detected.

9. Battery Cell Damage Protection: DJI Fly displays a warning prompt when a damaged battery cell is

detected.

10. Hibernation Mode: The battery switches o after 20 minutes of inactivity to save power. If the

battery level is less than 5%, the battery enters Hibernation mode to prevent over-discharge after

being idle for six hours. In Hibernation mode, the battery level indicators do not illuminate. Charge

the battery to wake it from hibernation.

11. Communication: Information about the voltage, capacity, and current of the battery is transmitted

to the aircraft.

Refer to the Safety Guidelines and the battery sticker before use. Users take full responsibility for all

operations and usage.

Other manuals for dji Mavic 3

Questions and Answers:

Need help?

Do you have a question about the dji Mavic 3 and is the answer not in the manual?

General

Type	Quadcopter
Product color	Black
Maximum speed	19 m/s
GPS (satellite)	Yes
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	40 min
Maximum flight time	46 min
Maximum ascent speed	8 m/s
Maximum descent speed	6 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	30000 m
Maximum pitch angular velocity	200 °/sec
USB ports quantity	2
Operating frequency	2400000 MHz
Battery voltage	15.4 V
Battery capacity	5000 mAh
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Maximum frame rate	120 fps
Camera shutter speed	8 - 1/8000 s
Image formats supported	DNG, JPEG
Video formats supported	H.264, H.265
Maximum image resolution	5280 x 3956 pixels
Maximum video resolution	5120 x 2700 pixels
Field of view (FOV) angle	84 °
Operating temperature (T-T)	-10 - 40 °C
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	-
Moving control functions	Backward, Downward, Forward, Upward
