19
ACTIVATE ZONE 2
BYPASS: NO YES
7/0 PANIC
ENABLE: NO YES
7/0 Panic
Select YES to configure the 7 and 0 keys as 2-button Panic
keys. To disable the option, select NO. Default is NO.
Zone 2 Bypass (7073/A, 7173 only)
Select YES to enable the bypass option on Zone 2. This zone
provides the bypass for door contacts. This zone must be
programmed into the panel.
Zone 2 Bypass Time (7073/A, 7173 only)
Enter the number of bypass seconds to elapse before the
bypass timer expires. Range is from 20 to 250 seconds.
Press any top row select key to enter the number of
seconds. Once the door strike relay is activated, the user
has five seconds to open the door connected to Zone 2.
The zone is then bypassed for the programmed time or
until the contact restores to normal. Ten seconds prior to
the expiration of the bypass time, the keypad beeps if the
door is still open. If the door remains open when the timer
expires a zone open/short is sent to the panel for Zone 2.
Default is 40 seconds.
Relock on Zone 2 Fault? (7073/A, 7173 only)
Select NO to leave the relay on when Zone 2 faults to
an open or short condition during bypass. Select YES to
turn the relay o when Zone 2 faults open or short during
bypass. Default is NO.
ZONE 2 BYPASS
TIME: 40
RELOCK ZONE 2
FAULT: NO YES
Installer Options
To Next Page
