E F x3 G x2 H x2 I x2 J K
Included
#2 Phillips
Screw Driver
25mm Spade Bit
To fit a new door
To retrofit existing door
10 mm Drill Bit
Drill
What you will need to retrofit existing door
Installation guidance
Locksmart Abode
Before installation
Check: Door thickness must be
38-55mm, Door frame ≥110mm
Check: Use the grub screw
located on the lock stem
assembly and reposition
the handle to suit your door
position. See diagram on right
Check: Existing lock has been removed
from door
Getting started
A B
C1 & C2
D
E F x3 G x2 H x2 I x2 J K
Lock stem
Grub screw
4
