Domino D320i Red User Manual

MAINTENANCE AND FAULT FINDING
5-10 L025317 Issue 5 July 2014
582 Controller Idle
(Multi Head
System)
The system is part of
a multi head “chain”
but has been
disabled (see install
options). This is for
information only.
If this controller needs to work
enable it in the install options
of the user interface.
583 External Interlock
has been opened
One or both
interlocks was
opened but is now
closed.
If the guards were not opened
check for a bad connection
on the interlock.
594 Safety Relay
Fault
There was a laser
start command
present while one or
both (CAT3/4)
interlocks where not
closed.
Make sure the interlocks are
closed before giving the laser
start input.
600 Irregular Laser
Off Procedure
The laser did not
stop when the DSP
expected it to.
Contact Domino
601 Laser Off Delay
Ends During
Laser On Delay
Laser parameter
misconfiguration in
message.
Contact Domino
602 Laser Off Delay
Retriggered
Laser parameter
misconfiguration in
message.
Contact Domino
603 Laser On Delay
Retriggered
Laser parameter
misconfiguration in
message.
Contact Domino
604 I2C Sensor Bus
Fault
Hardware
malfunction
Contact Domino
605 I2C Feature Bus
Fault
Hardware
malfunction
Contact Domino
606 Marking
Controller -
Transfer CRC
Fault
Marking Controller
malfunction
Contact Domino.
607 Marking
Controller - List
CRC Fault
Marking Controller
malfunction
Contact Domino.
1000 Non volatile
storage plugin
failed to load.
Internal fault in
software installation.
Contact Domino.
1001 Non volatile
storage not
connected.
Wrong system setup
or hardware not
working.
Contact Domino.
Status Message Cause Suggested Action
