MAINTENANCE
28
7/71, 12/56
TORQUE VALUES
ft lbf Nm
Airend to engine 29−35 39−47
Air filter to bracket 16−20 22−27
Autella clamp to exhaust 9−11 12−15
Baffle to frame 9−11 12−15
Blowdown solenoid valve 21−26 28−35
Discharge manifold to frame 29−35 39−47
Drive pins to engine flywheel 57−69 77−93
Drop Leg 53−63 72−85
Engine/airend to chassis 54−58 73−78
Euro−Loc adaptor to separator tank 58−67 78−91
Exhaust flange to manifold 17−21 23−28
ft lbf Nm
Fan guard 9−11 12−15
Fan to hub 12−15 16−20
Lifting bail bracket to engine 29−35 39−47
Oil pipe (−12jic) 71−88 96−11 9
Radiator/Cooler to baffle 9−11 12−15
Running gear front to chassis 63−69 82−93
Running gear rear to chassis 63−69 82−93
Running gear drawbar to axle 29−35 39−47
Separator tank cover 40−50 54−68
Separator tank to frame 18−22 24−30
Service pipe (−20jic) 106−133 143−180
Sight glass 40−50 54−68
Wheel nuts 62−70 85−95
