A Series Diesel Engine Air System 105
Air System Replacement
Procedures
Air Crossover Tube – Replacement
7mm
Loosen the hose clamps and position the hose so the
crossover tube can be remove.
Use a new gasket and new hoses and clamps as
required to install the air crossover tube.
Torque Value:
z Hose Clamps: 39 Nm [29 ft-lbs]
Intake Manifold Cover and Gasket –
Replacement
Preparatory Steps:
z Remove the high pressure fuel lines.
z Disconnect the cold starting aid.
z Remove the air crossover tube.
To Next Page
