A Series Diesel Engine Air System 106
12mm
Remove the manifold cover and complete the following
steps.
Caution : Keep the gasket material and any other
material out of the air intake.
Clean the sealing surface.
12mm
Install the gasket and cover.
Torque Value : 25.5Nm [19 ft-lbs]
To Next Page
