A Series Diesel Engine Air System 111
Exhaust Manifold and/or Gasket -
Replacement
Preparatory Steps:
z Remove the air crossover tube.
z Disconnect the air intake and exhaust
piping.
z Remove the turbocharger and gasket.
12mm
Remove the manifold and gasket.
Clean the sealing surface.
12mm
Install the manifold and gaskets.
Torque Value : 25.5Nm [19 ft-lbs]
Follow the sequence shown in the illustration.
To Next Page
