DTC 286: Injector 9 coil shorted 659 6
DTC 2312: Spark coil 5 primary open
or short to ground
1272 5
DTC 288: Injector 10 open or short to
ground
660 5
DTC 2313: Spark coil 5 primary
shorted
1272 6
DTC 289: Injector 10 coil shorted 660 6
DTC 2315: Spark coil 6 primary open
or short to ground
1273 5
DTC 1631: PWM1-Gauge1 open /
ground short
697 5
DTC 2316: Spark coil 6 primary
shorted
1273 6
DTC 1632: PWM1-Gauge1 short to
power
697 6
DTC 2318: Spark coil 7 primary open
or short to ground
1274 5
DTC 1633: PWM2-Gauge2 open /
g
round short
698 5
DTC 2319: Spark coil 7 primary
shorted
1274 6
DTC 1634: PWM2-Gauge2 short to
power
698 6
DTC 2321: Spark coil 8 primary open
or short to ground
1275 5
DTC 1635: PWM3-Gauge3 open /
ground short
699 5
DTC 2322: Spark coil 8 primary
shorted
1275 6
DTC 1636: PWM3-Gauge3 short to
power
699 6
DTC 2324: Spark coil 9 primary open
or short to ground
1276 5
DTC 1637: PWM4 open / ground
short
700 5
DTC 2325: Spark coil 9 primary
shorted
1276 6
DTC 1638: PWM4 short to power 700 6
DTC 2327: Spark coil 10 primary
o
p
en or short to
g
round
1277 5
DTC 1547: AUX analog Pull-Up/Down
4 high voltage
713 3
DTC 2328: Spark coil 10 primary
shorted
1277 6
DTC 1548: AUX analog Pull-Up/Down
4 low voltage
713 4
DTC 617: Start relay coil short to
power
1321 3
DTC 341: CAM input signal noise 723 2 DTC 616: Start relay ground short 1321 4
DTC 342: Loss of CAM input signal 723 4 DTC 615: Start relay coil open 1321 5
DTC 134: EGO1 open / lazy 724 10
DTC 1311: Cylinder 1 misfire
detected
1323 11
DTC 326: Knock1 excessive or erratic
signal
731 2
DTC 301: Cylinder 1
emissions/catalyst damaging misfire
1323 31
DTC 327: Knock1 sensor open or not
p
resent
731 4
DTC 1312: Cylinder 2 misfire
detected
1324 11
DTC 1643: Buzzer control short to
power
920 3
DTC 302: Cylinder 2
emissions/catalyst damaging misfire
1324 31
DTC 1641: Buzzer control ground
short
920 4
DTC 1313: Cylinder 3 misfire
detected
1325 11
DTC 1642: Buzzer open 920 5
DTC 303: Cylinder 3
emissions/catalyst damaging misfire
1325 31
DTC 1662: PWM6 short to power 925 3
DTC 1314: Cylinder 4 misfire
detected
1326 11
