Maintenance Section
-215-
Hydraulic Oil Level – Check
WARNING
At operating temperature, the hydraulic tank is
hot and under pressure.
Hot oil can cause burns.
Remove the filter cap only when the engine is
stopped, and the cap is cool enough to touch
with your bare hand. Remove the filter cap
slowly to relieve pressure.
1. Operate the lift truck for a few minutes to warm
the oil. Park the lift truck on a level surface, with
the forks lowered, mast tilted back, parking
brake engaged, transmission in NEUTRAL and
the engine stopped.
2. Raise the hood and seat assembly. Make sure
the air lift cylinder securely holds the hood
open.
3. Remove the dip stick/filter cap. Maintain the oil
level to the FULL mark on the dip stick/filter
cap.
