Operation Section
-166-
Mono-Ped Control System (Option)
Forward-Push the left side (2) of the pedal
for FORWARD direction travel.
Neutral-The lift truck should not move when
the Mono-Ped pedal is released..
Reverse-Push the right side (1) of the pedal
for REVERSE direction travel.
The MONO-PED pedal controls the speed and
direction of the lift truck. Pushing on the right side of
the pedal (1) causes the lift truck to move in
REVERSE. The optional reverse lights and optional
back-up alarm will be ON in the REVERSE position.
Pushing on the left side of the pedal (2) causes the
lift truck to move in FORWARD.
The speed of the truck increases as the pedal is
depressed
