Lubricant Viscosities and Refill Capacities
Lubricant Viscosities
LUBRICANT VISCOSITIES
FOR AMBIENT (OUTSIDE) TEMPERATURES
Compartment
or System
Oil
Viscosities
°C °F
Min Max Min Max
G424I(E)
G430FE,
G424P(E)
Engine
Crankcase
(Gasoline and
LP)
API SL
SAE
10W30
-20 +40 -4 +104
SAE 5W30 -30 +30 -22 +86
4TNE98 &
4TNE94L (T3)
Crankcase
(Diesel)
API CI4,
ACEA E5
SAE
10W40
-15 +50 -5 +122
Power Shift
Transmission
& Drive Axle
Housing
API CD/TO-2
SAE 10W -20 +22 -4 +72
SAE 30 +10 +50 +50 +122
Hydraulic and
Power
Steering
System
ISO 6743/4
HM
ISO VG 22 -30 +20 -22 +68
ISO VG 32 -20 +30 -4 +86
ISO VG 46 -10 +40 +14 +104
ISO VG 68 0 +50 +32 +122
Brake
Reservoir
(Only for
OCDB)
ISO 6743/4HM
ISO VG32 -20 +30 -4 +86
The SAE grade number indicates the viscosity of oil.
A proper SAE grade number should be selected
according to ambient temperature.
Refill Capacities
REFILL CAPACITIES - (APPROXIMATE)
Compartment or System Liters U.S Gal.
Engine Crankcase w/Filter
G424I & G424IE 2.4 liter
G424P & G424PE 2.4L liter
Gasoline & LP
5.7 1.56
Engine Crankcase w/Filter
G430FE 3.0 liter LP
4.3 1.14
Engine Crankcase w/Filter
4TNE98 &4TNE94L Diesel
9.2 2.43
Cooling System
w/Coolant Recovery Bottle
G424I & G424I(E) 2.4 liter
Gasoline & LP
8.5 2.25
Cooling System
w/Coolant Recovery Bottle
G430FE 3.0 liter
G424P & G424PE 2.4 liter
Gasoline & LP
9.0 2.38
Cooling System
w/Coolant Recovery Bottle
4TNE98 &4TNE94L Diesel
10.7 2.83
Fuel Tank - G, D Series
Gasoline or Diesel
51 13.47
Fuel Tank - GC Series
Gasoline
40 10.56
LP
G Series
15.2kg 33.5lb
GC Series
15.2kg 33.5lb
Powershift
Transmission
G, D Series
13.0 3.43
GC Series
11.2 3.0
Drive Axle
G, D Series
9.2 2.43
GC Series
10.0 2.64
Hydraulic & Power Steering System
34 8.98
Brake Reservoir (Only for OCDB)
0.6 0.16
