Operating Instructions Operating & Maintenance Manual
45
Optional Controls
9. Engine Speed Gauge - Indicates engine speed.
10. Discharge Air Temp. Gauge - Indicates in °F and °C. Normal operating range:
185°F/85°C to 248°F/120°C.
11. Engine Oil Pressure Gauge - Indicates engine oil pressure (psi (kPa).
12. Engine Water Temp Gauge - Indicates coolant temperature with normal
operating range from 180°F/82°C to 210°F/99°C.
13. Voltmeter - Indicates battery condition.
14. Spare
