Getting Started
No. Item Function
1 Navigation Control/
CENTER OK button
Press this multi-directional control up, down,
left, or right to move through menus and
program instructions; carry out the selection by
pressing the CENTER OK button.
2 Notification LED 1 This LED shows battery charging status.
3 Touch Screen Tap the screen with the stylus to write, draw, or
make a selection.
4 Notification LED 2 This LED shows the GSM/UMTS standby/
network status (Green). and GPS indicator
(amber)
5 Notification LED 3 This LED shows the following:
• A flashing Blue light for Bluetooth system
notification of powered-up and ready to
transmit radio frequency signal.
• A flashing Green light for Wi-Fi status.
• When both Bluetooth and Wi-Fi are enabled,
their lights flash alternately.
6 Notification LED 4 This LED shows messages and notifications.
7 Second Camera Use this camera for video call conversations or
to take self landscape photos.
8 OK Button Press to confirm your data entries, or to exit the
program in use.
9 START Button Press to open the Start menu.
10 INTERNET EXPLORER
MOBILE/VueFLO Button
Press to launch Internet Explorer Mobile. Press
this button to activate VueFLO when browsing
the Web.
11 Battery Compartment Open this compartment to insert the SIM/USIM
card, miniSD™ card and battery.
12 Keyboard Copper
Connector
Attach the copper part of the keyboard to this
to be able to use the keyboard. See "Using the
Hardware Keyboard" in chapter 2 to learn how
to attach the keyboard to the main unit.
