DORMA
3
ED 100/250
Safety instructions
Work on electrical equipment may only be performed
by properly qualified staff (electricians).
• DonotallowchildrentoplaywiththeED 100/250
or its rigidly mounted adjustment and control devices.
• Keepremotecontrolsoutofreachofchildren.
• Neverstickmetalobjectsintotheopeningsofthe
ED 100/250; otherwise you might sustain an
electric shock.
• IftheED 100/250 is mounted onto a metal door leaf,
you have to earth (ground) the door leaf properly.
• Alwaysusesafetyglasswhenmounting
glassdoorpanels.
Important technical data
WeightofED 100/250 12 kg
Powersupply 230VAC+/-10%50Hz
Fuse(byothers) 16A
Max.operatingnoise 50db(A)
Standards, laws, codes and regulations
Thelatestversionsofthecommonandcountry-specific
standards,laws,codesandregulationshavetobeobserved.
formation/provisions regarding the application of the
ED 100/250 at fire and smoke doors:
• Pleaseconsiderthetechnicalbulletinforthe
applicationofhold-opendevices.
• Pleaseusetheguidelinesforhold-opendevices
issuedbytheDIBt(GermanInstituteforCivil
Engineering)inBerlin.
Low-energy product
TheED 100/250 may be adjusted so that it meets the
requirements of a low-energy application (low-energy
operator) to DIN 18650, ANSI 156.19 and BS 7036-4.
During commissioning, the operator has to be adjusted in
accordance with the prevailing standard.
Therequiredsystemsafetyisensuredbythefollowing
means:
• Reduceddynamicforceatdoorleaf/contactforce
• Lowdrivingspeed
• Reducedstaticforceatdoorleaf/contactforce
• Forcelimitation
Theapplicationofadditionalsafetysensors(IRS-4)to
protecttheswingpathisnotexplicitlystipulatedbutshould
beconsideredasanoptioniftheindividualriskassessment
revealsthatfurthersensorsarerequired.Theprotectionof
thesecondaryclosingedgehastobeassessedindividually.
Risk assessment on the part of the installer
Duetospecialspatialconditionsandtheexpecteduser
groupsofthedoor,theapplicationofsafetysensorsmay,
however,alsobereasonableforalow-energyoperator.
Thereforethemanufacturer,i.e.theinstallerofthesystem,
hastoperformanindividualriskassessmentduringthe
planningofthedoorsysteminordertodecidewhether
additionalsafetyequipmentisrequiredornot.
Pleaserefertoourhomepagewww.dorma.com and consider
the provided “risk assessment form” under PRODUCTS
for further assistance when performing your individual risk
assessment.
Special requirements regarding the protection of people in
need of protection
Incasetheriskassessmentrevealsthatthereisahealthrisk
orriskofinjurycausedbythedoorhittingapersonusingthe
doorwithanunacceptableforce,anadditionalprotection
withtheaidofappropriatesafetyequipment(connectionofa
safetysensor)isrequired.
Thisisespeciallynecessarywhenpeopleinneedof
protection(children,elderlypeopleordisabledpeople)use
thedoor.
Dangers at closing edges
Automatic doors may cause hazards by crushing,
shearing, hitting and drawing-in at the different closing
edges.
Opposingclosingedge
Secondaryclosingedge
Mainclosingedge
Dangers caused by slide channel and arm
The slide channel and the arm may cause hazards by
crushing and shearing.
Residual risk
Dependingonthestructuralconditions,theprevailingdoor
versionandtheavailablesafetyequipment,residualrisks
(suchascrushingandhitting–withlimitedforce)cannotbe
excluded.
Allpeopleusingadooraregenerallyawareofthedanger
spotatthesecondaryclosingedgeofeveryswingdoor
(alsoatmanuallyoperateddoors).Thisdangerspotcannot
beinfluencedbythemanufactureroftheoperatoranda
protectionofthisclosingedgeoftencannotberealised
duetoitsconstructionandtechnicalfunction.Asuitable
clampingprotection(likearubberortextilecover)isavailable
inthespecialisedtradeandnotpartofthescopeofdelivery.
