3.5 Upgrade Cards
The Upgrade Cards allow you to extend the functional
range of the automatic swing door operator units ED 100
and ED 250. During the installation of the Upgrade Cards,
information between the control unit and the Upgrade Card
is exchanged and assigned. The desired function can be
used as long as the Upgrade Card is installed in the drive
unit.
• The first installed Upgrade Card becomes the container
module. The functions of additional Upgrade Cards
are saved in the container module. Each control unit
features only 1 container module.
• The status of the Upgrade Card is indicated by 3
integrated LEDs. The red LED lights in case of the
DCW Upgrade Card as soon as the DCW members are
logged on and it indicates that DCW telegrams are
being exchanged.
3.5.1 Combination options
There are several functions available.
The Upgrade Cards are colored in order to differentiate
between them.
Upgrade Card Color ED 100 ED 250
Full Energy blue X
Full Energy blue transparent X
Fire Protection red X
Fire Protection red transparent X
Professional green X X
DCW yellow X X
Barrier-free WC black X X
3.5.2 Upgrade Card Full Energy – blue/blue transparent
The Upgrade Card Full Energy allows you to make use of
the full setting range of the opening and closing speed
parameters as well as the opening and closing torque. It can
be used for 2-panel systems.
3.5.3 Upgrade Card Fire Protection – red/red transparent
The Upgrade Card Fire Protection is needed to set up a
hold-open system in accordance with EN 14637 or similar
standards. The line-monitored detector input for the
connection of the RM-ED or the integrated smoke detector
is only available with the installed Upgrade Card Fire
Protection. The Full Energy function will be automatically
activated. It can be used for 2-panel systems.
3.5.4 Upgrade Card Professional – green
The use of the Upgrade Card Professional allows you to
activate the functions nurse bed, extended hold-open time
and impulse relay. It can be used for 2-panel systems.
3.5.5 Upgrade Card DCW – yellow
The Upgrade Card DCW allows the connection of DCW-
compatible accessory components to the drive unit. It can
be used for 2-panel systems.
3.5.6 Upgrade Card Barrier-free WC – black
With the use of the Upgrade Card Barrier-free WC, the
inputs and outputs of the control unit are assigned with
the functions especially required for this application. The
required accessory components can be directly connected.
The Upgrade Card Barrier-free WC is not used for 2-panel
systems.
3.6 Accessories
In addition to an extensive range of accessories, many
activators, locking devices, safety sensors and accessories
of other manufacturers are available and could be used
together with the drive units ED 100 and ED 250.
dormakaba cannot guarantee the compatibility with devices
from other manufacturers. If those devices are always
used, the full functional range of the drive units may not be
available or the devices may not function properly.
The drive unit or the connected device may also become
damaged.
The operator can provide a maximum 1.5 A with 24 V DC for
external consumers. In case more current is required (even if
only temporarily), an external power supply is to be used in
order to prevent a malfunction of the drive unit.
3.6.1 Activator
In general, the following types of devices are activators:
radar motion sensors, passive infrared motion sensors,
pushbuttons, switches, sensor buttons, radio, IR-receivers,
access control systems, telephone and intercom systems.
Minimum requirements:
Operating voltage when supplied by the drive unit:
24 V DC +/- 5 %
Pulse duration:
min. 200 ms
Potential-free output:
(in case a signal input internal is used,
external detector or night/bank)
Energized output (telephone systems):
max. 24 V DC/AC +/- 5 %
3.6.2 Locking device
In general, the following types of devices are locking devices:
electrical door opener (E-opener), motor locks, multi-point
locking device with response contact, holding magnets.
Motor locks without a locking response can be directly
connected to the drive unit if the locking time is less than
4 seconds. In order to ensure the safe operation of the
combined drive unit and locking device, the locking device
must meet the following specifications:
Minimum requirements:
Operating voltage when supplied by the drive unit:
24 V DC +/- 5 %
Operating voltage with an external supply:
max. 48 V DC/AC
Load of the contact relay locking:
max. 1 A
Switch-on time electrical door opener:
min. 30 %
Switch-on time motor lock:
100 %
ED 100, ED 250
—
6
