ED100 / ED250 SERVICE MANUAL
—
21
4.4 Closing time Doors shall close from 90°
to 10° in 3 seconds or
longer as required in Table I
Doors shall close from 10°
to fully closed in not less
than 1.5 seconds
Sc – closing speed automatic mode
Factory setting: 25° / sec.
Adjustment range:
ED 100: 8 to 50° / sec.
ED 250: 8 to 60° / sec.
4.5 Force required to prevent a
stopped door from opening or
closing
Kinetic energy of a door in motion.
Table I provides minimum times
for various widths and heights
of doors for obtaining results
with this kinetic energy
Doors shall open with a manual
force:
To release a latch, if equipped
with a latch
To set the door in motion
To fully open the door
The forces shall be applied at 1"
[25 mm] from lead (latch) edge
of door
Force shall not exceed
15 lbf [67 N] measured
1" [25 mm] from the lead
edge of door at any point
during opening or closing
Shall not exceed
1.25 lbf-ft [1.69 Nm]
Not exceed 15 lbf [67 N]
Not exceed 30 lbf [133 N]
Not exceed 15 lbf [67 N]
Fo – Static force in opening direction
Factory setting: 13.5 lbf [60 N]
Adjustment range
4.5 lbf [2 N] to 33.7 lbf [150 N]
Range reduced for low energy
mode
Fc – Static force in closing direction
Factory setting: 13.5 lbf [60 N]
Adjustment range
4.5 lbf [2 N] to 33.7 lbf [150 N]
Range reduced for low energy
mode
hS – Support for manual mode in
"closed" position
hA – Adjustment of door activation
angle
hF – Power assist function
