DORMA AUTOMATICES, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211 Subject to change without notice
DL3463-050 08/2016 Lake Bluff, IL 60044 Fax: 847-249-3999
ED100 / ED250 SERVICE MANUAL
—
28
Parameter detail
Parameters / Display Value range
Unit
factory setting
= bold
Explanation
22. Push & Go
0 – 1 0 = off
1 = on
■ Following activation of the parameter, automatic opening of
door is started when it is manually moved out of the “closed”
position by an angle of 4° in the “open” direction.
■ Parameter hd must be set to 0 (door closer / automatic mode)
for this function.
■ For double doors, if active door is triggered by Push & Go,
passive door will also open.
23. Program switch type
0 – 4 0 Internal program switches are active.
1 ■ An external mechanical program switch with contacts is
connected to terminal board.
■ Internal program switch’s connector must be pulled out.
2 ■ An external DCW electronic program switch (EPS) is connected
to terminal board.
■ Internal program switch’s connector must be pulled out.
3 Control program switch via TMS software
4 ■ Electronic program switch DCW is installed, and operator is
also connected by the building management system to TMS
soft.
■ When PS is set to 4 (GLS DCW mixed mode), the program
switch functions can be changed from DCW EPS or TMS soft
(v1.9).
24. Electronic program
switch (EPS) DCW:
switch behavior
following a power
reset
0 – 1 0 ■ In event of a power failure, or if operator is deliberately
switched off, EPS will automatically switch to previously
adjusted function as soon as power supply returns.
Important: The time at which power returns might not be
during business hours and thus has an influence on insurance-
compliant locking.
1 ■ In event of a power failure, or if operator is deliberately switched
off, Electronic program switch (EPS) is automatically switched
to OFF position when power returns.
■ This function should be used if insurance-compliant locking is
required.
25. Internal program
switches – switch on
delay
0 – 1 0 Operator will preform function of internal program switch as soon
as internal program switch has been moved.
1 ■ After a delay of 10 seconds from when internal program
switches have been switched over, function is enabled.
■ This function is reasonable if user has to pass through door,
and its connected detectors / sensors, after function has been
converted.
■ An additional Night/Bank activator is not required.
26. Unlocking during
business hours
0 – 1 0 Door is always locked when it reaches “closed” position.
1 ■ In automatic mode, door will not lock when it reaches "closed"
position.
■ This achieves faster door opening when system is equipped
with motor locks.
■ If an electric strike opener is used, it must be suitable for
100% continuous duty factor to avoid possibility of damage.
27. Status relay function-
terminal block X7,
terminals 97-99, N/C
terminals 97-98, NO
0 – 6 0
Status relay is deactivated.
1 Status relay is activated as soon as door has reached set “closed”
position.
2 Status relay is activated as soon as door has reached set “open”
position.
3
Errors resulting in message(s) on internal display activates status
relay.
4 "Door closed and locked" activates status relay.
5 Errors or information resulting in message(s) on internal display
activates status relay (v1.9).
6 Status relay is activated when door is open further than “opening
angle” parameter OA. Parameter value can only be changed using
a hand-held device or by another learning cycle (v1.9).
