ATTACHMENT OF COMPONENTS TO UNREINFORCED
INDIVIDUAL DOOR MANUFACTURER'S LISTINGS.
ALTERNATIVE METHOD IS IDENTIFIED IN THE
COMPOSITE TYPE FIRE DOORS, UNLESS AN
DOORS AND TO WOOD OR PLASTIC FACED
4. CAUTION: SEX NUTS ARE REQUIRED FOR
ATTACHMENT OF COMPONENTS TO UNREINFORCED
INDIVIDUAL DOOR MANUFACTURER'S LISTINGS.
ALTERNATIVE METHOD IS IDENTIFIED IN THE
COMPOSITE TYPE FIRE DOORS, UNLESS AN
DOORS AND TO WOOD OR PLASTIC FACED
4. CAUTION: SEX NUTS ARE REQUIRED FOR
ED800-8 08102710 05/07
ED 800J X DROP - TOP JAMB DROP INSTALLATION TEMPLATE & MOUNTING
INSTRUCTIONS
Prepare door and frame according to template.
ED 800J X DROP X 830 - TOP JAMB DROP INSTALLATION WITH 830 ARM SHOE DROP
PLATE TEMPLATE & MOUNTING INSTRUCTIONS
Prepare door and frame according to template.
ED800-2 Rev.08/04
ED800-4 Rev.08/04
(224)
4-1/4
(44)
(108)
(10)
(24)
3/8
3. LEFT HAND DOOR SHOWN.
BOTTOM OF FRAME
REVEAL
NOTES:
C
OF 4-1/2" WIDE HINGE, 3/4" OFFSET PIVOT
1. DO NOT SCALE DRAWING.
2. DIMENSIONS ARE IN INCHES/(MM).
5. SEE CATALOG FOR ARM NUMBER
FOR NON STANDARD REVEALS.
FOR 1/4-20 MACHINE SCREWS USE No.7(0.201") DRILL & TAP
FOR No. 14 WOOD SCREWS USE 5/32" DRILL
FIVE (5) HOLES IN FRAME FOR PLATE
FOR 1/4-20 MACHINE SCREWS USE No.7 DRILL
FOR No.14 WOOD SCREWS USE 5/32" DRILL
FOR SEX NUTS USE 3/8" DRILL
TWO (2) HOLES IN DOOR FOR ARM SHOE
8-13/16
1-3/4
SEE
NOTE
# 5
2" TO 6" STD.
3-1/4
(83)
3-15/16
(100)
7/8" DIA. HOLE FOR
WIRE ACCESS
15/16
MINIMUM TO CEILING 1-3/4"
1-5/16
(33)
12-5/8
(321)
(525)
20-11/16
4-3/8
(111)
11/16
(17)
6. MAXIMUM OPENING ANGLE 115°
7. DOORS AND FRAMES MUST BE PROPERLY
REINFORCED.
ED800J X DROP
TOP JAMB DROP INSTALLATION - LOW CEILING CLEARANCE
(PUSH SIDE MOUNT)
8. AUXILIARY STOP, (BY OTHERS) ARE REQUIRED AT 115° FOR
INSTALLATIONS WHERE DOOR CAN OPEN FURTHER THEN 115°
(224)
1-3/8
(44)
(35)
(10)
(24)
3/8
3. LEFT HAND DOOR SHOWN.
BOTTOM OF FRAME
REVEAL
NOTES:
C
OF 4-1/2" WIDE HINGE, 3/4" OFFSET PIVOT
1. DO NOT SCALE DRAWING.
2. DIMENSIONS ARE IN INCHES/(MM). 5. SEE CATALOG FOR ARM NUMBER
FOR NON STANDARD REVEALS.
FOR 1/4-20 MACHINE SCREWS USE No.7(0.201") DRILL & TAP
FOR No. 14 WOOD SCREWS USE 5/32" DRILL
FIVE (5) HOLES IN FRAME FOR PLATE
FOR 1/4-20 MACHINE SCREWS USE No.7 DRILL
FOR No.14 WOOD SCREWS USE 5/32" DRILL
FOR SEX NUTS USE 3/8" DRILL
THREE (3) HOLES IN DOOR FOR PLATE
8-13/16
1-3/4
SEE
NOTE
# 5
ED800J X DROP X 830 ARM SHOE DROP PLATE
TOP JAMB DROP INSTALLATION - LOW CEILING CLEARANCE / NARROW TOP RAIL
2" TO 6" STD.
3-1/4
(83)
3-15/16
(100)
7/8" DIA. HOLE FOR
WIRE ACCESS
(PUSH SIDE MOUNT)
15/16
MINIMUM TO CEILING 1-3/4"
1-5/16
(33)
12-5/8
(321)
(525)
20-11/16
4-3/8
(111)
11/16
(17)
6. MAXIMUM OPENING ANGLE 115°
7. DOORS AND FRAMES MUST BE PROPERLY
REINFORCED.
2" MIN.
TOP RAIL
3/4" MAX.
1/2
(13)
7/8
(22)
INSTALLATIONS WHERE DOOR CAN OPEN FURTHER THEN 115°
8. AUXILIARY STOP, (BY OTHERS) ARE REQUIRED AT 115° FOR
