Install closer to door.
8900T AND 8900DE
8900PT
7
(RIGHT HAND DOOR)
(LEFT HAND DOOR)
(LEFT HAND DOOR)
(RIGHT HAND DOOR)
8
8900T
(RIGHT HAND DOOR)
(LEFT HAND DOOR)
Attach main arm to door closer.
(4)
QTY
METAL FRAMES
WOOD FRAMES
(4)
QTY
Place arm on top pinion as shown @ 45° angle. Secure with pinion screw.
6mm HEX KEY
6mm HEX KEY
QTY
(1)
INS NO.
PAGE
Rev.
08280990
3 of 14
08/13
