Dormakaba SVA 6 Series User Manual

3.2 Technical information
All SVA door locks
Temperature range -25°C to +70°C
Relative humidity: up to 95% at 55°C;
no condensation
Protection category: IP54
DIN direction: can be used left and right
except for SVA6xxx
Installation position: vertical
Tubular
frame locks
Solid door
locks
Backset: 35, 40 or
45mm
65, 80 or
100mm
Rear backset: 15mm 33 mm
Forend: 24mm wide,
270mm high,
angular/
square
20 mm or
24mm wide
235mm high,
round
Distance between
door handle and
locking cylinder:
92mm
for profile
cylinder
94mm
for round
cylinder
72 mm
profile
cylinder
74 mm round
cylinder
Nut to inner square: 9mm 9mm
Bolt throw: 20mm 20mm
SVA4000
Status messages via potential-free contacts
Contact load capacity 100mA at max. 30VDC
SVA6000
Status messages via potential-free contacts
DIN direction: left or right depending on
order
Supply voltage: 12 or 24VDC stabilized
(+/- 15%)
Power consumption: 0.15A (max. 0.3A)
Contact load capacity: 100mA at max. 30VDC
SVA2000 and SVA2000F
Supply voltage: 24VDC stabilized
(+/- 15%)
Power consumption: 0.05A (max. 0.3A)
Bus operation: DCW® bus or
CAN bus (ISO11898-3)
“Locked” signal: output switches to GND, 30
mA at max. 30 V DC
3.3 Variants
Versions of the SVA door locks are available for various
applications:
• The SVA 5000 is a mechanical door lock. When the
door is closed, the door lock locks automatically. The
SVA5000 is also suitable for retrofitting doors in
which no connection cable can be laid.
• The SVA4000 is an electrically monitored door
lock. When the door is closed, the door lock locks
automatically.
• The SVA6000 is an electrically monitored door
lock. When the door is closed, the door lock locks
automatically. In addition, the door handle can be
electrically engaged or disengaged on the access
side. This makes the door lock suitable for doors
that have access control from the outside but can
be opened from the inside at any time in the escape
direction.
• The SVA2000 is a motorized lock whose function
can be controlled electronically. When the door
is closed, the door lock locks automatically. It
is operated separately (Stand Alone) or on an
external control unit via a DCW® bus or a CAN bus.
DCW® operation on an electric door operator with
integrated control unit is also possible, e.g. with the
ED100/ED250. The SVA 2000 may only be used in
fire and smoke protection doors in combination with
the external Power Reserve module "SVP-PR DCW®"
(item no: 70922601)!
• The SVA2000F is a motorized lock with the same
functions as the SVA2000, which is also approved
for use in fire and smoke protection doors. The
SVA2000F contains an integrated Power Reserve
module. The SVA2000F cannot be switched to
"permanently open" because this function is not
permitted for use on fire and smoke protection
doors.
• The locks SVA 2000 and SVA 2000F are compatible
with an ED100 or ED250 from the ED firmware
version V2.200 upwards. If the EDs have an older
firmware version, this must be updated.
