CONNECTING THE EXTERNAL INJECTION (IE)
In order to use corrosive concentrates, the external injection model DOSATRON
is also delivered with an external injection hose.
CAUTION screw in the components carefully !
Model D3REIE
Step 3
8 cm
6 cm
25
%
2
1
4
3
Step 4
Step 1
Step 2
