SPECIFICATIE
D 3 RE 3000
D 3GL3000
D 3T
(1)
RE3000
D3RE2
D3GL2
D3T
(1)
RE2
Doorstroming : .........................................................................
(1)
...........................................................................................
(2)
...........................................................................................
Maximale temperatuur : ...............................................................
(1)
..............................................................................................
(2)
..............................................................................................
Inlaatdruk bij werking :
bar
PSI
0.30 - 6
4.3 - 85
0.30 - 6
4.3 - 85
Dosering vast of instelbaar :
%
Ratio
0.03 - 0.3
1:3000 - 1:333
0.2 - 2
1:500 - 1:50
Injectie capaciteit :
Mini l/h - Maxi l/h
US Fl. oz/min - MINI
US GPM - MAXI
0.003 - 9
0.0017
0.04
0.02 - 60
0.011
0.28
Aansluitingen (NPT/BSP):.......................................................
Capaciteit motor (elk 2 slagen van de zuigermotor): ..................
LET OP: de Dosatron is niet vooraf ingesteld, zie hoofdstuk
AFMETINGEN POMP
Diameter: cm ["] 11.2 [4 7/16] 11.2 [4 7/16]
Totale hoogte: cm ["]
53 [21] 48.5 [19 3/32]
Breedte: cm ["] 16 [6 5/16] 16 [6 5/16]
Gewicht: ± kg [lbs] 1.6 [3.5] 1.7 [3.7]
D3RE5
D3GL5
D3T
(1)
RE5
D3RE10
D3GL10
D3RE25IE
(2)
....................10 l/h mini 3 m
3
/h maxi [1/3 US Pint/min - 14 US GPM]
................100 l/h mini 3 m
3
/h maxi [0.4 US Pint/min - 14 US GPM]
....................10 l/h mini 2 m
3
/h maxi [1/3 US Pint/min - 9 US GPM]
....................................................... 40 °C [104 °F]
....................................................... 60 °C [140 °F]
....................................................... 40 °C [104 °F]
0.30 - 6
4.3 - 85
0.50 - 6
7 - 85
0.50 - 4
7 - 57
0.5 - 5
1:200 - 1:2
1 - 10
1:100 - 1:10
5 - 25
1:20 - 1:4
0.05 - 150
0.028
0.7
0.1 - 300
0.056
1.4
0.5 - 500
0.2818
2.2
................................................. Ø 20x27 mm [3/4”]
........................................ ongeveer 0.53 l [0.14 US Gallons]
INSTELLING VAN DE DOSERING
11.2 [4 7/16] 11.2 [4 7/16] 11.2 [4 7/16]
53.8 [21 3/16] 53.8 [21 3/16] 66 [26 1/8]
16 [6 5/16] 16 [6 5/16] 16 [6 5/16]
1.8 [3.9] 2 [4.4] 4 [8.8]
AFMETING VERPAKKING:
55.2 x 16.5 x 14.5 cm [21 7/8" x 6 5/8" x 5 3/4"]
GEWICHT VERPAKKING : ongeveer 2 - 4 kg [~ 4.4 - 8.8 US lbs]
VERPAKKING BEVAT: 1 Dosatron/ 1 bevestigingssteun/ 1 zuigs-
lang / 1 aanzuigfilter/ Externe Injectie slang voor de “IE” modellen /
1 gebruiksaanwijzing
