SPECIFICATIONS & DIMENSIONS
Version D3IL10
Operating flow range:10l/h min.3m3/h max. [0.4-14US gpm]
Max. operating temperature: .............................40°C [104°F]
Operating pressure:
bars 0.5-6
psi 7-85
Externally adjustable dosing rate:
% 1 - 10
Ratio 1:100 - 1:10
Concentrated product injection rate:
Min. l/h - Max. l/h 0.1—300
US Fl. oz/min - MIN 0.056
US Fl. oz/min - MAX 1.4
Connection (NPT/BSP male gas fittings): .......... Ø20 x 27mm [3/4”]
Hydraulic motor capacity (every two clicks of the piston):
approx.0.53L [0.14US Gallons]
ATTENTION! The DOSATRON is not pre-set, please refer to the
paragraph on Adjusting the dosing (without pressure), page 29
DIMENSIONS
Diameter: cm [“] 11.2 [4 7/16]
Total height: cm [“] 53.8 [21 3/16]
Overall width: cm [“] 16 [6 5/16]
Weight: ± kg [lbs] 2 [4.4]
PACKAGING
PACKAGE COMPOSITION:
1 DOSATRON/1 mounting bracket for DOSATRON/1 suction hose for
concentrate/1 strainer/ 1 quick start guide
PACKAGING DIMENSIONS:
55.2 x 16.5 x 14.5 cm [21 7/8” x 6 5/8” x 5 3/4”]
PACKAGE WEIGHT:
Approx. 5 kg [~ 11 US lbs]
