The device can be connected to the water supply line by means of 20 mm
interior diameter flexible pipes (drinking water certified, where applicable) fixed
with swivel fittings Ø 20 x 27 mm [3/4”]. Make sure that the water flows in the
same direction as the arrows (water flow direction) on the device.
Whenever possible, install the DOSATRON high enough to be able to read
and adjust the dosing on the graduated scale in % or ratio.
CHANGING THE DOSING SCALE
The DOSATRON dosing rate can be adjusted according to two scales:
percentages and ratios. These scales are positioned on either side of the
injection assembly.
Depending on the liquid circulation direction in the hydraulic installation, and
on the direction in which the dosing pump is mounted on its bracket, it may be
necessary to change the orientation of this scale.
fig 7 fig 8
— Unscrew the fixing nut on the injection assembly by hand to release it, then
pull it downwards and rotate it half a turn to see the correct dosing adjustment
scale.
