INSTALLATION TIPS
The DOSATRON must be assembled in by-pass as shown below. An in-line
assembly is possible but not recommended because it does not enable the
dosing pump to be easily isolated for maintenance (necessary to cut off the
water supply).
fig 17
Item
Description
1 Filter
2 Pressure Reducer
3 Isolation valve
4 Clear water / stock solution valve
5 Fast priming / flushing / Dosatron test / sampling
valve
6 Water hammer protection device
7 Non-return valve
To prolong the service life of the DOSATRON, we recommend fitting an
upstream filter (e.g 60 microns - 300 mesh, depending on your water quality).
This precaution is essential if the water contains impurities or particles,
especially when using water from a well or surface water
