REPLACING THE INJECTION SEALS
Frequency: at least once a year.
Contact DOSATRON, or a dealer to select the appropriate seal kit for your
dosing pump.
Dismantle the injection assembly in accordance with the instructions in the
Removing/Refitting the injection assembly section, page 35.
ATTENTION! Do not use metal tools or utensils.
D3IL10
Replace the suction valve:
• Unscrew the suction valve locking nut.
• Release the suction valve by pulling it through the middle of the injection
assembly
Replace the dosing pump body O-ring:
• Completely unscrew the dosing locking nut
• Release the snap ring by spreading the lugs.
• Remove the dosing body by pushing it through the sleeve
• Using your thumb and forefinger, pinch the component and the seal; push
towards the other side to distort the seal.
• Continue until you can grip the protruding part of the seal, then pull it out of
the groove.
• Refit the dosing pump body into the injector sleeve using the centring pins.
• Refit the snap ring, ensuring that it is correctly positioned in its groove.
• Retighten the dosing locking nut completely.
• Finish by refitting the suction valve and its locking nut.
Replace the injector sleeve O-ring:
• Follow the method explained above.
