Functions (water) - 15
Version 1.36
02/2004
10. Fix the tank with the included retaining screw (1) and connect the hose, place the hose clamp (2)
and the two wires (3) to the inlet valve inside.
11. Connect the flexible metal water hose to the valve at the rear side of the tank (4)
(Do not forget to place the sealing ring).
12. Connect the water block to the water cock (see the included instructions) and connect the flexible
metal water hose. (5)
1
4
3
2
5
13. Open the water cock, plug in the power cord and switch the machine on. Check the machine
performance and ensure that no hose or connection is leaking.
14. Install tank lid and left machine cover.
