AEF-A.DOC 02/2003
13
• At any time, it is possible to stop the machine by using the emergency stop (point 8, fig
4).
• The maximum working time of each speed is 60 minutes, and then the machine will stop
automatically.
4.5 – AUTOMATIC OPERATION
• Turn the general switch into position I, and verify if Emergency Stop is unlocked and
then press the power button (point 1, fig.4), the display (point 2 and 3, fig.4) will light
up.
• Close the safety bars (point 3, fig.3). If you lift up the bars, the machine will stop
immediately.
• The machine starts in manual mode, to change it into automatic mode you just have to
press button (point 7, fig.4) [ ] to choose the mode.
• When the automatic mode is selected, the displays 9,13 and 14 light and stay in Program
1.
• To select the program number, use the buttons 11[ ] and 12 [ ].
• The button 15 [ ], starts and restarts the selected program, the button 16 [ ]
stops the program and the working process.
