44 TOW-BEHIND DR
®
FIELD and BRUSH MOWER
Parts List - Wheels and Push Bar Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 222341 Support, Axle Pivot, LH
02 222351 Support, Axle Pivot, RH
03 123211 Bolt, 5/16"-18 x .75", HCS, GR5, ZP
04 110761 Nut, Nylon Lock, 5/16"-18, ZP
05 221431 Axle, Adjustable, LH
06 221441 Axle, Adjustable, RH
07 221501 Bushing, 1.00" ID x 1.25" OD x 1.00"
08 228861 Bolt, 3/8"-16 x 1.25", HCS, GR8, ZP
09 222531 Washer, Lock, 3/8", Split, GR8, ZP
10 228871 Washer, .385" ID x 1.50" OD x .25", ZP
11 221591 Pin Assy, 1/2", w/Spring
12 222571 Spacer, 2.5" x 1.25" x .75", Nylon
13 160861 Bolt, 1/4"-20 x 1.25", HCS, ZP
14 110731 Nut, Nylon Lock, 1/4"-20, ZP
15 222321 Wheel, 18" x 6.5-8, 1.0" Bore x 3.0" Long
16 221511 Bushing, .75" ID x 1.00" OD x 1.25", Flange
17 222401 Deflector, Wheel, LH
18 222411 Deflector, Wheel, RH
19 222461 Bolt, 3/8"-16 x .75", HCS, GR8, ZP
20 221341 Push Bar
21 150451 Bolt, 5/16"-18 x 1.75", HCS, ZP
22 222271 Guard, Deck Front
23 152501 Bolt, 1/4"-20 x .75", HCS, w/Flange
24 112381 Washer, Flat, 1/4", USS, ZP
25 101811 Washer, Lock, 1/4", Split, ZP
