DR FIELD and BRUSH MOWER - Controls, Assembly, and Connections

12 TOW-BEHIND DR
®
FIELD and BRUSH MOWER
TOW-BEHIND DR FIELD and BRUSH MOWER Controls and Features
NOTE: The model shown in Figure 1 may look slightly different from your machine.
Figure 1
Throttle Control
Blade Control Knob
Kawasaki 17 HP Engine
(Briggs
& Stratton 13HP will
look di
ff
erent than shown
)
Electric-Start Key Switch
Oil Fill
Fuel Tank
Battery
Off
On
Fuel Shut-Off
Valve
Remote Control Panel
Left Step
& Mow™ Height Adjuster
Fuel Filter
Versa-Hitch™
Push Bar
Out-Rigger™ Tow Bar
Front Guard
Out-Rigger™ Tow Bar
Locking Pin
Right Step & Mow™
Height Adjuster
Pulley Cover
