DR FIELD and BRUSH MOWER User Manual

2 TOW-BEHIND DR
®
FIELD and BRUSH MOWER
Specifications
13 HP Model 17 HP Model
Machine Warranty 2 year Residential, 90 day Commercial 2 year Residential, 90 day Commercial
Engine Warranty 2 year Residential, 1 year Commercial 2 year Residential, 2 year Commercial
Engine 13 HP Briggs & Stratton Engine, Electric
Start, OHV, 1 Cast-Iron Sleeve, Full
Pressure Oil Pump w/ Oil Filter, 48 oz
Oil Capacity, Dual-Element Air Filter,
Fuel Pump, Electronic Ignition
17 HP Kawasaki KAI Engine, Electric
Start, V-Twin OHV, 2 Cast-Iron Sleeves,
Full Pressure Oil Pump w/ Oil Filter, 58
oz Oil Capacity, Dual-Element Air Filter,
Fuel Pump, Electronic Ignition
Fuel Tank 2.5 Gallons, Gasoline, Unleaded 2.5 Gallons, Gasoline, Unleaded
Wheels 18" Dia. x 6-7/8" Wide, All Terrain
Tread, 28 PSI, Sealed, Tubeless
18" Dia. x 6-7/8" Wide, All Terrain
Tread, 28 PSI, Sealed, Tubeless
Remote Control Panel Key Switch, Throttle Lever, and Blade
Engage Switch, 5' from Versa-Hitch™ to
front of Control Panel.
Key Switch, Throttle Lever, and Blade
Engage Switch, 5' from Versa-Hitch™ to
front of Control Panel.
Deck Offset 0%, 50%, 75%, 100%
Out-Rigger™ Tow Bar
0%, 50%, 75%, 100%
Out-Rigger™ Tow Bar
Adjustable Cutting Height 5", 6-1/4", and 7-1/2"
Step & Mow™ Wheel Axle
and Versa-Hitch™
5", 6-1/4", and 7-1/2"
Step & Mow™ Wheel Axle
and Versa-Hitch™
Cutting Width 44" 44"
Cutting Capacity 4' High Grass, 1-1/2" Thick Saplings 6' High Grass, 1-1/2" Thick Saplings
Blade Tip Speed 195 MPH or 17,180 Ft/Min 195 MPH or 17,180 Ft/Min
Swinging Blades “PRO-TEK” Swinging Blades
2 Blades, .25" Thick x 16-1/2" Long
Hardened Steel
“PRO-TEK” Swinging Blades
2 Blades, .25" Thick x 16-1/2" Long
Hardened Steel
Deck
11 GA (.12" thick) Welded Steel 11 GA (.12" thick) Welded Steel
Spindle 1-3/8" Dia. Shaft with 2 Sealed 30 mm
Bearings
1-3/8" Dia. Shaft with 2 Sealed 30 mm
Bearings
Spindle Housing
7 GA (.18" thick) Welded Steel 7 GA (.18" thick) Welded Steel
Push Bar 1-1/4" Dia. x 11 GA (.12" thick) Steel
Tubing
1-1/4" Dia. x 11 GA (.12" thick) Steel
Tubing
Front Guard
3/16" Thick Compressed Rubber 3/16" Thick Compressed Rubber
Belt
5/8" x 53.8" Type BP51 5/8" x 53.8" Type BP51
Electric Clutch
75 ft-lb Ogura 75 ft-lb Ogura
Fuses 20 AMP Type AGC Fuse (Engine
Alternator Circuit)
7 AMP Type AGC Fuse (Clutch Circuit)
20 AMP Type AGC Fuse (Engine
Alternator Circuit)
7 AMP Type AGC Fuse (Clutch Circuit)
Machine Overall Width 64-1/4" Outside the Wheels 64-1/4" Outside the Wheels
Machine Overall Length 110" with the Tow Bar fully extended 110" with the Tow Bar fully extended
Machine Overall Height 28-1/4" 28-7/8"
Machine Weight at Tow Bar 35 lbs. 27 lbs.
Machine Weight 442 lbs. 465 lbs.
Shipping Weight 617 lbs. 641 lbs.
Shipping Crate 73" x 60" x 36" 73" x 60" x 36"
