12 DR
®
WALK-BEHIND LEAF & LAWN VACUUM
DR WALK-BEHIND LEAF
&
LAWN VACUUM Controls and Features
NOTE: The model shown in Figure 1 may look slightly different from your machine.
Figure 1
Nozzle Door Lever
Nozzle Door
Debris Bag Assembly
Drive Clutch Lever
(Self-Propelled Models)
Throttle
Gear Shift Lever
(Self-Propelled Models)
Briggs
&
Stratton 6.0 HP
Quantum Engine
Manual Recoil Start Handle
Gas Fill
Electric-Start Switch
(Electric-Start Models)
Primer Bulb
Oil Fill
Battery
Muffler
Spark
Plug
Vacuum Nozzle
Height Adjuster
Optional Vacuum
Hose Cover
Nozzle Door Lift Rod
Dust Tammer™
Top Shield
