DR Manual-Start - Push User Manual

54 DR
®
WALK-BEHIND LEAF & LAWN VACUUM
Parts List – Top Shield and Bag Assembly - All Models
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
130 21849 Top Shield, Plastic
131 21815 Bracket, Bag, Channel, RH
132 21907 Seal, Bag
133 21920 Tube, Handle, Brace, RH
134 21919 Tube, Handle, Brace, LH
135 21814 Bracket, Bag, Channel, LH
136 21819 Bracket, Nozzle Door, Adjuster
137 21806 Bag Assembly
138 21807 Bar, Lift, Nozzle Door
139 21889 Rod, Lift, Nozzle Door
140 21878 Plate, Bag, Latch
141 21839 Grip, Lever, Lift
142 21915 Switch, Interlock, Bag, E/S Model
21916 Switch, Interlock, Bag, Push Model
143 21810 Bolt, Carriage, 1/4"-20 x 1-3/4"
144 21847 Harness, Wire Assy, Push Model
21843 Harness, Bag Wire Assy, E/S Model
145 21923 Washer, 1/4", FC, ZP
146 21872 Nut, Lock, Nylon Insert, 1/4"-20, UNC
147 21896 Screw, 10-24 x 1", HEX
148 21922 Washer, #10, SAE,ZP
149 21873 Nut, Lock, Nylon Insert, 10-24, UNC
150 21921 Tie Wrap
151 21876 Pin, Screw, 1/4"-28
152 21927 Washer, Flat, 5/16", ZP
153 21875 Nut, Lock, Nylon, 5/16"-18 UNC
154 21910 Spring, Lever, GZ
155 21837 Washer, Fiber
156 21903 Screw, Cap, 5/16"-18 x 2"
157 21848 Bolt, 1/4"-20 x 2-1/4" x 3/4"-N, HF
(Electric Start Model only)
158 21897 Screw, Cap, 1/4"-20 x 1" HCS, ZP
159 21906 Screw, Cap, 5/16"-18 x 1-3/4", ZP
160 21823 Bracket, Switch, Start, E/S Model only
161 21924 Washer, 1/4", SAE, ZP
162 21856 Label, Ear, Eye, Breathing
163 21860 Label, Read
164 21887 Rod, End, Ball Joint, 3/8", NF
Ref# Part# Description
165 21891 Screw, Cap, 3/8"-16 x 1-1/2", ZP
166 21874 Nut, Lock, Nylon Insert, 3/8"-16, UNC
167 21900 Screw, Cap, 3/8"-16 x 2-1/2", ZP
168 21838 Seal, Bag, Top Shield Front, 1.8ft Long
169 21870 Nut, 3/8"-24, NF
170 21803 Screw, 1/4"-20 x 3/4", HWH
171 21929 Washer, Fender, 1/4", ZP
172 21898 Screw, Cap, 1/4"-20 x 4", HCS, ZP
173 21866 Nut, Acorn, 1/4"-20
174 21854 Label, Danger, Flying Debris
175 21859 Label, Nozzle Door
184 21879 Plate, Shift Control, Anti-Rotation
(Self-Propelled Model only)
185 21895 Screw, Cap, 10-24 x 1-1/4"
(Self-Propelled Model only)
188 21883 Plug, Snap, Rivet, 0.166" Dia.
(Push Model only)
189 21884 Plug, Snap, Rivet, 0.232" Dia.
(Push Model only)
Not Illustrated
21822 Grommet, Clutch Cable
